TRUMPF TruMark Station 5000 Laser Marking System - Compact, All-Aound Marking Solution

Overview:
Due to its intelligent, ergonomic design, the compact TruMark Station 5000 can be used as both a standing and a seated work station. We equip the machine with linear axes in the X and Y direction and rotary axes with various clamping systems, according to your requirements. The marking station offers the possibility of workpiece flow through transfer for integration in a flow line. The openings in the side of the housing offer excellent flexibility so that the TruMark Station 5000 can be expanded in line with your requirements. Its flexibility and its suitability for diverse application scenarios make the TruMark Station 5000 the true all-around solution of the TRUMPF marking systems.

Specs:
MAXIMUM WORKPIECE DIMENSIONS (W X H X D): 680 mm x 500 mm x 700 mm
MAXIMUM WORKPIECE WEIGHT: 50 kg
DIMENSIONS OF WORK STATION (W X H X D): 860 mm x 2000 mm x 1310 mm
TRAVERSE PATH OF THE Z AXIS: 500 mm 380 mm for TruMark 5010
TRAVERSE PATH OF THE X AXIS: 300 mm
TRAVERSE PATH OF THE Y AXIS: 300 mm

Industries:
Medical
Electronics
Aerospace
Tooling & Machining
Packaging

Why choose Headland as your machine provider?
With our 54 OEM-certified and factory trained service engineers located nationwide, Headland is committed to you beyond delivery and installation; offering breakdown support, OEM genuine spare parts, preventative maintenance and software support.

Want to learn more?
For full specs please download the attached brochure. Otherwise if you would like to discuss this machine with us in more depth please reach out.
