Taiwanese Centre Lathe, Ø 530mm Turning Capacity, Ø 58mm Bore

EXIMUS MODEL LA-530 SWING CENTRE LATHES - MANUFACTURED IN TAIWAN (Qld Government: DETE 65255 Approved Model)

The New LA range of precision lathes are available with 58mm Spindle bore, 430/530mm swing over the bed & 550/800/1100/1700mm between centres. (Qld Government: DETE 65255 Approved Model)

Lei Shin Machinery is one of Taiwan's leading manufactures of conventional and CNC lathes. Whitelaw Engineering machinery have supplied hundreds of these high quality centre lathes to tool rooms, schools, training colleges, automotive workshops and engineering companies throughout the Oceania region.

Don't take the risk by buying inferior quality products for your business, visit our or call for details on the complete range of Eximus machine tools manufactured in Taiwan.

MACHINE FEATURES:
• One piece solid cast base enhances the machine life and overall accuracy
• Wide (300mm) 12” bed way to absorb vibration
• Spindle supported by 3 point precision bearings NTN/NSK of Japan
• Headstock gears heat treated then hardened and ground
• Universal enclosed gearbox incorporating metric & imperial thread capabilities
• Foot operated spindle brake
• Removal gap piece to bed
• Powered longitudinal and cross feeds
• Metric or imperial lead screw

SPECIFICATION:

Swing over bed: … Ø 532 mm
Swing over cross slide: … Ø 372 mm
Distance between centres: …550/800/1100/1700 mm
Spindle nose: …D1-6 cam lock
Spindle bore: …58 mm
Number of spindle speeds: …12
Spindle speed range: … 27-1600rpm
Spindle motor: …Teco 7.5 HP 415V 3 phase

For more information please download the attached machine brochure, or feel free to call one of our sales team today on .

'Huge Range of Optional Equipment and Tooling'
--------------------------------------------------------------------------------
* Specifications subject to change without notice.

Delivery Australia Wide, competitive freight rates available. Call us on for a quote.
