UNIVERSAL TOOL GRINDER (MODEL: TG-230)

FULLPOWER UNIVERSAL TOOL GRINDER MODEL TG-230
With attachments for saws, planer blades, cutterheads & router bits the TG-230 is a very versatile grinder suited to most small to medium grinding applications.

SPECIFICATIONS:
Maximum tool length: 260mm
Maximum tool diameter: 230mm
Maximum saw diameter: 508mm
Shaft diameter: 40mm
Grinding wheel diameter: 150mm
Grinding wheel speed: 4000rpm
Grinding wheel motor: 1hp
Coolant motor: 1/8hp

STANDARD EQUIPMENT INCLUDED WITH MACHINE:
40mm Arbor with dividing head & tailstock
1” Compound arbor & dividing head (with assorted reducer bushes)
Flat knife grinding attachment
Saw grinding attachment
Router grinding head
Diamond grinding wheel
Coolant system for tool cooling
Manual lubrication system for slides & bearings
Operating tools
Operators manual

*Disclaimer*
Note: All photos and pricing are indicative only and have been prepared in good faith and with due care. Photos provided may include some optional features. Please contact us for an accurate quotation.
