VCF850/850L Multi Purpose Machining Centre Series Details

DOOSAN MACHINE TOOLS VCF850/850L Multi Purpose Machining Centre Series Details
CALL NOW AND DO A DEAL! ADD THIS ASSET TO YOUR WORKSHOP
WE OFFER MACHINERY SOLUTIONS AT AFFORDABLE PRICES.
Order Code: I8014

Features:
Built In Spindle Motor
Spindle Oil Cooler
Portable MPG
Coolant System
Fully Enclosed Guarding with Door Interlocks
Work Light
Operator Training
In House Service and Support Australia Wide



Specifications:
ORDER CODE: I8014
MODEL: VCF850/850L
X Travel (mm): 2000/3000
Y Travel (mm): 850
Z Travel (mm): 800
B Travel (deg): 220 (+110 -110)
C Travel (deg): 360
Table Size (mm): 2500/3500 x 870
Rotary Table Size (mm): 500/800
Table Capacity (kg): 3500
Spindle - Table (mm): 100-900 (3 Axis)
Spindle - Table (mm): -40-760 (5 Axis Vertical)
Spindle - Table (mm): 295-1095 (5 Axis Horiz)
Spindle Taper: BT40 - Big Plus
Spindle Speed (rpm): 12,000-18,000
Spindle Motor (kW): 22-32
Rapid Traverse (m/min): 40
Guideways: Roller LMG
Tool Arm Type (No.): 30/60
Control: Doosan Fanuc I Series /
Control: Fanuc 31i /
Control: Heidenhain TNC 640
Programming: EZI Guide I Conversational
Programming: / Heidenhain
Axis Motion: 3, 4 or 5 Axis Simultaneous
