VM MOTORI MARINE MR504LX 175HP (120kW) ENGINE

110kW / 150HP 4000rpm diesel marine engine.

• 4 stroke turbocharge and after-cooled,
• Direct injection diesel engine with electronically controlled common rail injection.
• Cooling controlled by separate fresh and salt water circuits, with extractable hoses for easy maintenance.
• Lube oil, water and air circuits designed to reduce external flexible pipes to a minimum to reduce loss of liquids in the bilge.
•Auxiliary devices driven by Poly-V belt to ensure excellent power transfer and long life.
• Electrical circuit protected by reactivate-able valves
• 110kW / 150HP 4000rpm
• 4 cylinder
• 250kg dry weight

Scope of Supply:
• 12V Starter motor
• Panel with electric instruments
• Alternator 12V-110A
• SAE 6.5"
• Variable geometry turbocharger
• Air and oil, fuel filters mounted
• Drain oil pump
• Freshwater engine cooling system with seawater heat exchanger
• Engine lubricating oil cooled by heat exchanger seawater cooled
• Bronze seawater circulating pump with impeller un special rubber
• Centrifugal pump for freshwater circulation
• Stainless steel exhaust gas/seawater mixer
• Flexible mounts
