Vertical Mast Lift - 25AM, 25 ft 2 in Platform Height, Most Rigid Mast

JLG 25AM Vertical Mast Lifts
Push Around Vertical Mast Lifts

Features:
Most rigid mast in the industry for operator comfort and stability
Six-wheel design for improved maneuverability
Long battery duty cycles and an automatic charger for increased productivity

Quick Specs:
Platform Height Elevated: 25 ft 2 in
Overall Width: 29 in
Platform Capacity: 350 lb

General Specifications:
Working Height: 31' / 9.45 m
Platform Height: 25' 2" / 7.67 m
Platform Capacity: 350 lb / 159 kg
Standard Platform: 26 x 25.5" / 66 x 65 cm
Overall Height (Stowed): 77.5" / 1.97 m
Overall Base Width: 29" / 74 cm
Overall Base Length: 49" / 1.24 m
Overall Length (Without Platform): 47" / 1.19 m
Overall Height (Tilted Back): N/A
Overall Length (Tilted Back): N/A
Ground Entry Height: 19" / 48 cm
Outrigger Footprint Length: 62" / 1.57 m
Outrigger Footprint Width: 53" / 1.35 m
Distance to Wall (Front): 5" / 13 cm
Distance to Wall (Side): 13" / 34 cm
Weight (AC): 825 lb / 374 kg
Weight (DC): 905 lb / 411 kg
Rear Wheels: 10 x 2" / 25 x 5 cm
Front Caster Wheels: 6 x 2" / 15 x 5 cm

JLG Industries is dedicated to delivering top-tier, innovative, and sustainable access equipment that enhances productivity and guarantees safety on job sites around the world. With decades of expertise, a commitment to continuous improvement, and a focus on customer success, JLG stands as a trusted partner in the industry. Order now and experience unmatched quality and reliability with JLG!
