Whitney 3400XP Punch - Plasma Machine

Achieve the lowest cost of equipment ownership with Whitney™ Combination machines.
The Hypertherm© HPR260 High Speed Plasma system combines with the power of hydraulic punching to produce precision parts from plate up to 12mm thick.

High speed, dross-free plasma cutting, clean hydraulic punching, and precision forming work together to produce complete parts in one operation. Parts flow to bending, robotic welding or assembly.

Hydraulic punching is the lowest cost, most accurate way of producing holes. You determine whether standard tooling or the very tough premium TuffSkin punches are best for your application. Full bodied tooling, insert punches and forming tools, all available in standard or TuffSkin, expand the capabilities of your plasma-punch combination. The Tooling Configuration helps you choose the right tooling for a specific job.

A variety of integrated, automatic and semi-automatic material handling equipment further enhances plasma-punch machine productivity.

The 3400 XP (Xtreme Performance) plasma-punch combination machine features the patented Rail Tool Changer with nine stations. Each station accommodates punch and die tooling to punch up to 127mm diameter holes.

36 ton of hydraulic punching power and Hypertherm HPR260 Plasma system equals high productivity.

Features:
Cartridge-style tooling for easy off-line set-up and quick cartridge placement.
Powerful work clamps, with multiple positioning choices, to secure material.
Wide drop door (1500 x 600) for easy, lightning fast removal of completed parts.
36 tons of hydraulic punching power to quickly punch, form and mark parts in one operation.
Faster rapid speeds, faster torch ignitions, faster drop door speeds.
Hypertherm© HPR260 provides higher cutting speeds with high definition quality.
Automated material handling solutions PartHANDLER-II

Technical specifications:

Sheet sizes: 1500 x 3500 without repositioning.
Max plate thickness: 12mm
Punching capacity: 360KN (36T)
Tool changer: 9 stations,
Small parts removal: 1500 x 600mm
