XCMG is the 4th largest construction machinery company in the world.
Compact design fits through narrow aisles, doorways and elevators.
Efficient DC drive system, better power-saving than hydraulic drive.
Proportional drive gives smooth control.
Zero emission and non-marking tires ensure environment- friendly operation.
Zero turning radius enables better manoeuvrability.
Max. Working height - 5.6 m
Max. Platform height - 3.6 m
Load capacity - 230 Kg
Load capacity of extended platform - 90 Kg
Max. Occupant Capacity - 2
Min. ground clearance (pit protector rising/descending) - 65/15 mm
Min. Turning radius (inner/outer wheel) - 0.4/1.55 m
Lifting motor - 1.3 kW
Lifting/Descending duration of platform - 27-37/23-33 S
Max. Traveling speed at low level - 4 Km/h
Max. Traveling speed at high level - 0.5 Km/h
Max. gradeability - 25%
Max. Inclination (side/forward and backward) - 1.5/2.5
Battery - 2x12/85 v/Ah
Charger - 24/15 v/A
Tire specification - 254x76
Total machine weight - 920 Kg
STM Equipment is the market leader in sales of new & used EWP equipment.
At STM Equipment we strive to be Australia’s number one provider of Access & Lifting solutions to new and existing customers. Our Sales & Operations team has over 50 years of experience in the access industry. We specialise in 10-year re-certification of EWP equipment, preventative maintenance, and scheduled servicing.
At STM Equipment no job is too big or small, and we are happy to assist you in any of your equipment needs Australia-wide.
Need Transport? Then ask about our Nationwide delivery service today.
Call our team of specialists today.
