XCMG is the 4th largest construction machinery company in the world.
Compact design fits through narrow aisles and doorways.
Ask about our Trailer packages.
Efficient DC drive system, better power-saving than hydraulic drive.
Proportional drive gives smooth control.
Zero-emission and non-marking tires ensure environment - friendly operation.
Zero turning radius enables better manoeuvrability.
Max. Working height - 7.8m
Max. Platform height - 5.8m
Load capacity - 230kg
Load capacity of extended platform - 115kg
Max. Occupant Capacity - 2
Min. ground clearance (pit protector rising/descending) - 70/20mm
Min. Turning radius (inner/outer wheel) - 0/1.75m
Lifting motor - 3.3kW
Lifting/Descending duration of platform - 13-30/25-35 S
Max. Traveling speed at low level - 4.5 Km/h
Max. Traveling speed at high level - 0.8Km/h
Max. gradeability - 25%
Max. Inclination (side/forward and backward) - 1.5/3
Battery - 4×6/225 v/Ah
Charger - 24/30 v/Ah
Tire specification - 323×100
Total machine weight - 1580 kg
a Overall length (no ladder) - 1900 (1680) mm
b Overall width - 810 mm
c Overall height (platform folded) - 2160 (1830) mm
d×e Working platform dimension (Length×Width) - 1670×740 mm
Length of extension platform - 900 mm
f Wheelbase - 1360 mm
STM Equipment is the market leader in sales of new & used EWP equipment.
At STM Equipment we strive to be Australia’s number one provider of Access & Lifting solutions to new and existing customers. Our Sales & Operations team has over 50 years of experience in the access industry. We specialise in 10-year re-certification of EWP equipment, preventative maintenance, and scheduled servicing.
At STM Equipment no job is too big or small, and we are happy to assist you in any of your equipment needs Australia-wide.
Need Transport? Then ask about our Nationwide delivery service today.
Call our team of specialists today.
