YANMAR DIESEL ENGINE TS230RS

YANMAR TS230RS 23HP 2200RPM

Yanmar widens your power selection with two more top utility models – TS190 & TS230

Higher Output – Heavier Loads
Long Stroke, Larger Displacement
Superb Combustion Efficiency
Superior Fuel Economy & more Fuel Tank Capacity
300% More life from Lube Oil
Durability Designed into Every Part
TS230RS – Specifications
Continuous Rating Output 19.0hp 2200rpm
1-Hour Rating Output 23.0hp 2200rpm
Cylinders 1
Combustion Direct Injection
Cooling System Water – Radiator
Starting System Hand & Electric
Fuel Tank Capacity 21.5 litres
Bore x Stroke 112 x 115 mm
Displacement 1.132 litres
Dry Weight (electric start) 203 kg
Length 963.5 mm
Width 468 mm
Height 657 mm


ACCESSORIES

Standard Accessories

Fuel filter
Maintenance and inspection tools
Starting handle
FO tank (complete)
Air cleaner (complete)
Exhaust silencer (complete)
V-belt for radiator fan
Bolts and washer stub shaft
Standard Spare Parts
