YLM - CNC electric tube bender CNC-50 MS-AE [made in Taiwan]

The machine is equipped with a powerful functioning CNC controller. The controller employs a windows operation system in combination with the use of Ying Han self-developed CNC control software.

Outstanding features include easy generation of bending parameters, 3D workpiece simulation function and single step operational simulation function, etc. These provide users with safe, easy and humanized control features.

Fully electric CNC pipe bender, All Electric Multi Stack CNC tube Bending machine

SPECIFICATION
Model CNC50MS-AE
Specification 50
Max. Tube O.D. Bending Capacity (mm) ? 50
Max. Tube Wall Thickness (mm) 2.5
Material MILD STEEL
CLR 180
Max. Bending Radius Difference (mm) 80
Max. Bending Angle (°) 190
Mandrel Working Distance (mm) 2500

Manufacture Speed
Tube Feeding Speed (mm/sec) 839
Tube Rotation Speed (°/sec) 390
Tube Bending Speed (°/sec) 120

Repeatability
Tube Feeding Precision (mm) ± 0.1
Tube Rotation Precision (°) ± 0.1
Tube Bending Precision (°) ± 0.1

Overall Weight (kg) 5200
Operating Height (mm) 1145
Machine Length (mm) 5269
Machine Width (mm) 1676
Machine Height (mm) 1914

Available in in single stack.
