The machine is equipped with a powerful functioning CNC controller. The controller employs a windows operation system in combination with the use of Ying Han self-developed CNC control software. Outstanding features include easy generation of bending parameters, 3D workpiece simulation function and single step operational simulation function, etc. These provide users with safe, easy and humanized control features.
Fully electric CNC pipe bender, All Electric Multi Stack CNC tube Bending machine.
SPECIFICATION : Model CNC70MS-AE
Max. Tube O.D. Bending Capacity (mm) ? 70
Max. Tube Wall Thickness (mm) 3
Material MILD STEEL
CLR 180
Max. Bending Radius Difference (mm) 90
Max. Bending Angle (°) 190
Mandrel Working Distance (mm) 2500
Manufacture Speed
Tube Feeding Speed (mm/sec) 1143
Tube Rotation Speed (°/sec) 1371
Tube Bending Speed (°/sec) 156.8
Repeatability
Tube Feeding Precision (mm) ± 0.1
Tube Rotation Precision (°) ± 0.1
Tube Bending Precision (°) ± 0.1
Overall Weight (kg) 5397
Operating Height (mm) 1170
Machine Length (mm) 5570
Machine Width (mm) 1637
Machine Height (mm) 1914
