YLM - CNC electric tube bender CNC181MS-AE [made in Taiwan]

The machine is equipped with a powerful functioning CNC controller. The controller employs a windows operation system in combination with the use of Ying Han self-developed CNC control software. Outstanding features include easy generation of bending parameters, 3D workpiece simulation function and single step operational simulation function, etc. These provide users with safe, easy and humanized control features.

Fully electric CNC pipe bender, All Electric Multi Stack CNC tube Bending machine

SPECIFICATION
Model CNC181MS-AE
Specification 181
Max. Tube O.D. Bending Capacity (mm) ? 180
Max. Tube Wall Thickness (mm) 4
Material MILD STEEL
CLR 370
Max. Bending Radius Difference (mm) 150
Max. Bending Angle (°) 190
Mandrel Working Distance (mm) 4500
Manufacture Speed Tube Feeding Speed (mm/sec) 837
Tube Rotation Speed (°/sec) 506
Tube Bending Speed (°/sec) 19.5
Repeatability Tube Feeding Precision (mm) ± 0.1
Tube Rotation Precision (°) ± 0.1
Tube Bending Precision (°) ± 0.1
Overall Weight (kg) 20850
Operating Height (mm) 1369
Machine Length (mm) 9528
Machine Width (mm) 3147
Machine Height (mm) 2364
