The machine is equipped with a powerful functioning CNC controller. The controller employs a windows operation system in combination with the use of Ying Han self-developed CNC control software. Outstanding features include easy generation of bending parameters, 3D workpiece simulation function and single step operational simulation function, etc. These provide users with safe, easy and humanized control features.
Fully electric CNC pipe bender, All Electric Multi Stack CNC tube Bending machine
SPECIFICATION
Model CNC38MS-AE
Specification 38
Max. Tube O.D. Bending Capacity (mm) ? 38
Max. Tube Wall Thickness (mm) 2
Material MILD STEEL
CLR 180
Max. Bending Radius Difference (mm) 50
Max. Bending Angle (°) 190
Mandrel Working Distance (mm) 2000
Manufacture speed
Tube feeding speed (mm/sec) 1693
Tube rotation speed (°/sec) 780
Tube bending speed (°/sec) 283
Repeatability
Tube feeding Precision (mm) ± 0.1
Tube rotation Precision (°) ± 0.1
Tube bending Precision (°) ± 0.1
Overall weight (kg) 3190
Operating height (mm) 1200
Machine length (mm) 4432
Machine width (mm) 1324
Machine height (mm) 1630
