YLM - CNC hybrid tube bending machine - CNC-70 [made in Taiwan]

Features of Hybrid Tube Bender
1. The series of machine employs hydraulic valves and integrated circuits ti control bending motion individually, which will extend the service life of he hydraulic parts.
2. Large bending machine is equipped with a manually adjusted digital flow regulation valve to control the speed of bending motion.
3. Servo drive provides high accuracy in bending positioning, that ensures high quality bending.

Suitable industries: Exhaust pipe for automotive and motorcycle, Vehicle frame, Handle bar, Car seat, Exercise equipment, Furniture, Architecture, Aircraft

CNC pipe bender, Hydraulic Pipe Bending Machine, tube bender with hydraulic tube bending machine, CNC Automatic Tube Bending Machine

SPECIFICATION
Machine Name CNC-70MS-6A
Max. tube o.d. bending capacity(Mild steel CLR1.5D)(mm) 70x2.2
Range of CLR (°) 180
Max. bending radius difference (mm) 90
Max. bending angle (°) 190
Mandrel working distance (mm) 2500
Manufacture speed Max. Tube feeding speed (mm/sec) 904
Tube rotation speed (mm/sec) 437
Max. Tube bending speed (mm/sec) 92
Repeatability Tube feeding Precision (mm) ± 0.1
Tube rotation Precision (mm) ± 0.1
Tube bending Precision (mm) ± 0.1
Overall weight (Kgs) 5170
Machine length (mm) 5646
Machine width (mm) 1556
Machine height (mm) 1914
Operating height (mm) 1170
