Suitable for the shrinking of various metal pipes with different material and different shape. Forming shapes can be convex, concave, sectional, long & flat, square, V-shape, open elbow, flat elbow…etc. The design of the tooling varies with work-piece & customers' requirements.
Conventional models - tube end-forming machine, pipe end forming machine
- Suitable for the shrinking for various metal pipes with (1)different material. (2)different shape.
- All the parts are made under very strict quality control, so the quality of machine is in high level and the specification is standardized.
- Equipped with emergency stop device. Both manual & automatic operations are available.
- Shrinking stroke 150 m/m. The length of working piece is 4,500 m/m Max. (but no limit on the minimum length).
- An additional feeding system can be added to the machine. The operating security is greatly increased because the operators just do the unloading & collecting job of finished pipes.
- Forming shapes can be convex, concave, sectional, long & flat, square, V-shape, open elbow, flat elbow...etc. The design of the tooling varies with work-piece & customers requirements.
