***Key features:
AC motor provides you with a maintenance-free experience!
IP67-rated waterproof protection on AC wheel motors for a longer lifespan
Swing-out tray easy to service
Battery Management System (BMS)+ Machine control system provide dual protection
***Warranty
2 Year full parts
5 Year Lithium Battery
***Mobility and Stability
Platform Capacity 230kg (Max. Number of Workers 2)
Capacity on Deck Extension 113kg (Max. Number of Workers 1)
Drive Speed (Stowed) 4km/h
Drive Speed (Raised) 0.8km/h
Turning Radius (Inside) 0.1m
Turning Radius (Outside) 1.6m
Up/Down Time 20s/24s
Gradeability 25%(14°)
Max. Working Slope (Lateral/Vertical) 1.5°/3°
***Power and control system
Lifting Motor 24V/3.3KW
Drive Motor 2x0.65KW
Control Proportional Control
Drive Front Wheels
Brake Front Wheels
***Dimensions
Platform Width: 0.74m
Overall Width: 0.81m
Platform length: 1.65m
Overall length: 1.85m
Platform extension: 0.91m
Gross Weight: 1620kg
