ZOOMLION 43X-5RZ (FOUR-AXLES) Truck-mounted Pump

ZOOMLION 43X-5RZ (FOUR-AXLES) Truck-mounted Pump.

ADVANTAGE INTRODUCTION
- Energy Saving: Self-adaptive variable power distribution control technolog
- High-Efficiency: Good site adaptability (one side support)
- High-Reliability: 8 years or 400,000 m³ without crack, making it equivalent to European standard.
- Intelligence: Full self-diagnosis before, after and during pumping to ensure working safely.
- Easy maintenance: Advanced easy-maintenance technologies, making maintenance time reduced by 50-75%.

BOOM
Maximum vertical reach: 43m
Maximum horizontal reach: 39m
Maximum depth reach: 30.5m
Minimum unfolding height: 9.1m
Section numbers: 5
Boom type: RZ
Pipeline diameter: 125mm

PUMP
Maximum theorical output: 140/90m3/h
Maximum theorical pressure on concrete: 70/110bar
Concrete cylinders (diam. x stroke): 230mm x 2100mm
Hydraulic circuit: Open

CHASSIS
Chassis brand: Multiple Choices
