CUTS BIG JOBS DOWN TO SIZE.
Designed with a fully welded tubular frame for a strong, stable backbone, and hydro-gear transaxles that provide increased torque, a smoother ride, and longer life. The ZT XL 48? features a 4.5-inch deep 11-gauge fabricated desk with an optimised airflow design.
The professional grade quality of the ZT XL was built for big jobs. This is a residential machine with heavy-duty features that make users forget they’re not on a commercial mower. Designed with a Kawasaki V-Twin Engine and a 10.5 litre fuel capacity, this unit cuts big jobs down to size.
KEY FEATURES
This unit will make you forget that you’re on a residential mower.
11-Gauge Fabricated Deck
Hydro-Gear Transaxles
Fully Welded Tubular Frame
23hp Kawasaki FR691 V-Twin Engine
Model: AGU915261
Engine Manufacturer: Kawasaki FR691V
Horsepower / Displacement: 23 HP / 726 CC
Drive System: Hydro-Gear® ZT-2800 Transaxles
Fuel Capacity: 10.5 L
Ground Speed: 12 KM/H Forwards, 4.8 KM/H Backwards
Deck Size: 48?
Deck Material: 11 GA.
Deck Construction: Fabricated
Number Of Spindles: 3
Blade Tip Speed (FPM): 18,000 FPM
Spindle Housing Material: Steel
Spindle Bearings: Sealed Bearings
Deck Engagement: Electric Warner
Deck Lift System: Foot Operated. Dial Selection
Cutting Width: 48 Inch
Cutting Positions / Height: 13 Cutting Positions / 38.1 MM – 114 MM
Wheels Front: 11 X 6 – 5 Smooth Pneumatic
Wheels Rear: 20 x 10 – 10 Turf
Seat 18 Inch Plush High Back W/ Padded Arm Rests. Seat Slider & Seat Isolation Standard
Foldable ROPS: N/A
Weight: 304.3 KG
Length: 1968.5 MM
Width : 1384.3 MM With Chute Up, 1530 MM With Chute Down
Height : 1066.8 MM
Warranty: 4 Year / 400 Hour
